DIN 1.0114 Structural Steel Bar



DIN 1.0114 is German structure steel grade, equivalent to Chinese Q235C, EN S235C, ASTM A53.



DIN 1.0114 is a steel material. It is a product produced in the United States according to the United States ASTM A283. Q stands for the yield of this material. The 235 behind it refers to the yield value of this material, which is about 235MP. And as the thickness of the material increases its yield value decreases. Due to the moderate carbon content, the overall performance is better, and the strength, plasticity and welding properties are well matched and are the most widely used.



Rolled into wire rod or round steel, square steel, flat steel, angle steel, I-beam, channel steel, window frame steel and other steel, medium thick steel plate. It is widely used in construction and engineering structures. It is used to make steel bars or to build factory house frames, high-voltage transmission towers, bridges, vehicles, boilers, containers, ships, etc., and is also used as a mechanical part that does not require high performance. C, D grade steel can also be used for some professional steel.



Mechanical properties:



Tensile strength (σb/MPa): 375-500



Elongation (δ5/%):


≥26 (a≤16mm) ≥25(a>16-40mm)

≥24(a>40-60mm)

≥23(a >60-100mm)

≥22(a>100-150mm)

≥21(a>150mm)

where a is the thickness or diameter of the steel. In the plate, it is the most common material
