WELDOX 1300 High Strength Steel Plate
Weldox 1300 is a general structural steel with a minimum yield strength of 1300 MPa. Typical application are load carrying structures having very high demands on low weight.
Typical applications include load-carrying structures that place very high demands on low weight. SSAB developed Strenx 1300 for building the lightest possible steel solutions or providing an alternative to other materials.
WELDOX 1300 benefits include:
- Good weldability with excellent HAZ strength and toughness
- Exceptional consistency within a plate guaranteed by close tolerances
- High impact toughness which provides for good resistance to fractures
- Superior bendability and surface quality
Chemical Composition:
| C *) (max %) | Si *) (max %) | Mn *) (max %) | P (max %) | S (max %) | Cr *) (max %) | Cu (max %) | Ni*) (max %) | Mo*) (max %) | B *) (max %) | ||
| 0.25 | 0.50 | 1.40 | 0.010 | 0.003 | 0.80 | 0.30 | 3.0 | 0.70 | 0.005 | ||
Mechanical Properties:
| Thickness (mm) | Yield strength Rp0.2 (min MPa) | Tensile strength Rm (min MPa) | Elongation A5 (min %) |
| 4.0 - 15.0 | 1300 | 1400 - 1700 | 8 |
