24 July 2021 5000 Series Aluminum Alloy
5026 Aluminum Alloy Plate
5026 aluminum is a 5000-series aluminum alloy: the main alloying addition is magnesium, and it is formulated for primary forming into wrought products. 5026 is the Aluminum Association (AA) designation for this material. In European standards, it will be given as EN AW-5026. A95026 is the UNS number. Additionally, the EN chemical designation is AlMg4,5MnSiFe.
Chemical Composition:
| Chemical Elements | Metric | English |
|---|---|---|
| Aluminum, Al | 88.15 - 94.65 % | 88.15 - 94.65 % |
| Chromium, Cr | <= 0.30 % | <= 0.30 % |
| Copper, Cu | 0.10 - 0.80 % | 0.10 - 0.80 % |
| Iron, Fe | 0.20 - 1.0 % | 0.20 - 1.0 % |
| Magnesium, Mg | 3.9 - 4.9 % | 3.9 - 4.9 % |
| Manganese, Mn | 0.60 - 1.8 % | 0.60 - 1.8 % |
| Other, each | <= 0.05 % | <= 0.05 % |
| Other, total | <= 0.15 % | <= 0.15 % |
| Silicon, Si | 0.55 - 1.4 % | 0.55 - 1.4 % |
| Titanium, Ti | <= 0.20 % | <= 0.20 % |
| Zinc, Zn | <= 1.0 % | <= 1.0 % |
| Zirconium, Zr | <= 0.30 % | <= 0.30 % |
